Battery Input Data

• Battery Type: Lead-acid or Li-lon.
• Battery Voltage Range (V): 40-60V.
• Max. Charging Current (A): 90A.
• Max .Discharging Current (A): 90A.
• Charging Curve: 3 Stages/Equalization.
• External Temperature Sensor: Optional.
• Charging Strategy for Li-Ion Battery: Self-adaption to BMS.

PV String Input Data

• Max. DC Input Power (W): 4680W.
• PV Input Voltage (V): 370V (100V - 500V).
• MPPT Range (V): 125V - 425V.
• Full Load DC Voltage Range: 240V - 425V.
• Start-up Voltage (V): 150V.
• PV Input Current (A): 11A.
• No .of MPPT Trackers: 2.
• No. of strings per MPPT Tracker: 1 1.

AC Output Data

• Rated AC Output and UPS Power (W): 36000W.
• Max. AC Output Power (W): 3960W.
• Peak Power (off grid): 2 times of rated power, 10 S.
• AC Output Rated Current (A): 15.7A.
• Max. AC Current (A): 18A.
• Max Continuous AC Passthrough (A): 35A.
• Power Factor: 0.8 leading to 0.8 lagging.
• Output Frequency and Voltage: 50/60Hz:220/230/240V ac (Single Phase).
• Grid Type: Single Phase.
• Current Harmonic Distortion: THD<3%(Linear Load<1.5%).

General Data

• Operating Temperature Range (C): -25-60C, >45C Derating
• Cooling: Fan
• Noise(dB): <30
• Communication with BMS: RS485;CAN
• Weight (Kg): 20.5
• Size (Length x Width x Height mm): 580 x 330 x 208mm
• Protection Degree: IP65
• Installation Style: Wall mounted
• Warranty: 5 Years
